Описание
Функции
• Low insertion loss and high return loss
• High reliability, and save maintenance cost
• Pre-embedded fiber is polished in high quality
• Can be reusable with easy disassembly and assembly
• Can work stably in harsh environment, like severe coldness and dust, high temperature, high humidity, etc
• Few special installation tools required, installation is simple and fast, with less than 30 seconds averagely;
• low technical requirements for the operators
Приложения
• Telecommunication networks
• FTTX, FTTH (Fiber to the Home)
• Fiber testing and testing equipment
• FTTH Drop Cable, 86 socket outlet, and ONU
Технические характеристики
Connector Type | LC/UPC | |
Applicable Cable | 0.9mm, 2.0mm, 3.0mm Cable; 2.0×3.0mm FTTH Drop Cable | |
Fiber Diameter | 125um | |
Coating Diameter | 250um | |
Fiber Mode | single mode | |
Insertion Loss | ≤0.2dB (max. 0.5dB) | |
Return Loss | UPC≥50dB | |
Lifespan | 10 years | |
Tensile Strength | >30N | |
Temperature Cycling | IL<0.3dB; RL<5dB | |
Mechanical Performance | Assembly Repeatability | ≥5 times |
Drop (1.5m height) | ≥10 times | |
Durability | ≥500 times | |
Working Environment | Относительная влажность | ≤95% (@±30°C) |
Atmospheric Pressure | 60kpa~160kpa | |
Operating Temperature | -40°C~+85°C | |
Storage Temperature | -40°C~+85°C | |
