Description
FOSCYA4 Dome Type Heat Shrinkable Fiber Optic Splice Closure (FOSC) is heat shrinkable sealing and suitable for uncut cables.
Specification:
| Model | FOSCYA4 |
| Type | Dome type |
| Sealing Structure | Heat shrinkable |
| Number of Inlet/Outlet ports | 4 ports |
| Cable Diameter | 3 ports×16mm, 1 port×25mm |
| Maximum Capacity | Bunchy: 96 fibers;Ribbon: 144 fiber |
| Capacity per Splice Tray | Bunchy: single layer:12 fibers; dual layers: 24 fibers;Ribbon: 6pcs |
| Quantity of Splice Tray | 4pcs |
| Body Material | PC |
| Sealing Material | Thermoplastic rubber |
| Assembling method | Aerial, direct buried, pipelined, wall mounting, manhole |
| Dimension | 440(H)×190(D)mm |
| Net Weight | 2.35~2.6KG |
| Temperature | -40℃~65℃ |
Main Components:
| Item | Name | Usage | Quantity |
| 1 | Housing (Cover) | To protect splices of fiber optic cables | 1pc |
| 2 | Splice Tray | To fix Fiber Splice Protective Sleeves | Max. 4pcs |
| 3 | Fiber Holding Tray | To store loose tube fibers | 1pc |
| 4 | Housing (Base) | To fix internal and external structure | 1pc |
| 5 | Plastic Hoop | To fix Housing Cover and Base | 1pc |
| 6 | Sealing Grommet | To seal Cover and Base | 1 set |
Standard Accessories:
| Item | Name | Usage | Quantity |
| 7 | Heat Shrinkable Protective Tubes and Branching Clip | To seal fiber optic splice closure | As per capacity |
| 8 | Fiber Splice Protective Sleeves | To protect fiber splices | Same as capacity |
| 9 | Nylon Tie | To fix buffer tubes with fibers inside | 8pcs |
| 10 | Grounding Wire | To connect with grounding device | 1pc |
| 11 | Abrasive Cloth | To polish fiber optic cable | 1pc |
| 12 | Labelling Paper | To label fibers | 1 set |
| 13 | M10 Wrench | To screw nuts for strength member | 1pc |
| 14 | Hanging Hoop | To install on wall and pole | 1 set |
| 15 | Heat Shrinkable Fixing Tube (Mass) | To seal fiber cables | optional |
| 16 | Aluminum-foil Paper | To protect cable ports when heated | 1pc |
| 17 | User Manual | To instruct installation | 1pc |
Optional Accessories:
| Item | Name | Usage | Quantity |
| 1 | Valve | To perform pressure and sealing testing | 1pc |
| 2 | Grounding Device | To derive metallic components of fiber cable | 1 set |
| 3 | Buffer Tube | To protect fibers and be fixed on splice trays | specified |
| 4 | Desiccant | To desiccate air in FOSC after sealing | 1 bag |
